Refer BS 530A40 Rod Specifications
Supplier of EN18 Standard Rectangular Bar in Mumbai, View BS 530A40 Hexagonal Bar American Standard
| Internal Standard | Equivalent Grades | |||||
|---|---|---|---|---|---|---|
| BS | DIN | IS | EN | SAE/AISI | ||
| EN18 | 530A40 | 37Cr4 | 40Cr1 | EN18 | 5140 | |
EN18 Steel Black Bar
BS970 EN18 Hexagonal Bar
Steel EN18 Bright Bar
EN18 Alloy Steel Square Bar
EN18 Medium Alloy Steel Rod
EN18 BS970 Flat Bar
EN18 Grade Forged Bar
EN18 Standard Rounds
Stockist of EN18 Standard Rectangular Bar in India, Have a look on Weight Chart
| Hex Size (mm) | Weight (kg/m) |
|---|---|
| 10 | 0.54 |
| 12 | 0.78 |
| 14 | 1.08 |
| 16 | 1.54 |
| 18 | 1.89 |
| 20 | 2.27 |
| 22 | 2.77 |
| 24 | 3.27 |
| 27 | 4.00 |
| 30 | 4.84 |
| 32 | 5.65 |
| 36 | 6.98 |
| 40 | 8.75 |
| 45 | 10.75 |
| 50 | 12.87 |
View BS 530A40 Medium Alloy Steel Rod Chemical Composition
Carbon
.35 – .45
Mangenese
.60 – 1.00
Silicon
.10 – .35
Sulfur
.050 MAX
Phosphorus
.050 MAX
Density
7.85 g/cm³
Modulus of Elasticity
210 GPa (30.5 x 10^6 psi)
Thermal Conductivity
45 W/m·K
Thermal Expansion
11.7 x 10^-6 /°C
Melting Point
1425-1540°C (2600-2800°F)
Refer EN18 Grade Steel Hex Bar Mechanical Strength
Impact KCV
55 Joules Min
Max Stress
850-1000 n/mm2
Hardness
248-302 HB
0.2% Proof Stress
680 N/mm2 Min
Yield Stress
700 N/mm2 Min
Elongation
9% Min
| Export to | Price changes and the expected delivery |
|---|---|
| South Korea | 5 % extra | 7 days |
| Japan | 5 % extra | 7 days |
| Sri Lanka | 5 % extra | 5 days |
| Maldives | 5 % extra | 7 days |
| Bangladesh | 5 % extra | 14 days |
