Table of Content
- EN24 Round Bar Specification
- Weight Chart of EN 24 Square Bar
- EN 24 Flat Bar Price list
- Equivalent Material of EN 24 Steel Hexagonal Bar
- Surface Finish of Steel EN 24 Rounds
- Common types of EN 24 Round Bar
- EN 24 Grade Black Bar Chemical Composition
- Mechanical Properties of EN 24 Standard Rod
- EN 24 BS970 Hexagon Rod Physical Properties
DIN 34CrNiMo6 Square Bar Weight Per Meter available with Quenching & tempering
Refer EN 24 Round Bar Price ex Mumbai
| Size | Weight |
|---|---|
| mm | Kg |
| 12 x 12 | 1.14 |
| 16 x 16 | 2.02 |
| 20 x 20 | 3.16 |
| 30×30 | 7.11 |
| 40 x 40 | 12.6 |
| 50 x 50 | 19.8 |
| 25 x 25 | 4.94 |
| Size | Price in USD | Price in Thailand | Price in Kuwait |
|---|---|---|---|
| 36MM | US $ 1.13 | THB 41.83 | KWD 0.35 |
| 60MM | US $ 1.61 | THB 59.59 | KWD 0.50 |
| 100 MM | US $ 1.72 | THB 63.62 | KWD 0.53 |
| 105MM | US $ 1.80 | THB 66.63 | KWD 0.55 |
| 110 MM | US $ 1.85 | THB 68.48 | KWD 0.57 |
| Standard | Value |
|---|---|
| BS970: 1955 | EN24 / EN24T |
| BS970/PD970 | 817M40 / 817M40T |
| European | 34CrNiMo6 |
| Werkstoff No. | 1.6582 |
| European Standard | EN10277-5 |
| SAE (AISI) | 9850 |
| US SAE (AISI) | 4340 |
| Din | 40NiCrMo84 |
| French AFNOR | 35NCD6 |
| Werkstoff No. | 1.6565 |
Check EN 24 Square Bar stock available in H8 Precision Ground Finish
| Surface Finish | |
|---|---|
| CD | Cold drawn |
| BD | Bright drawn |
| HRAP | Hot rolled annealed and pickled |
| P | Polished |
| SRE | Slit rolled edge |
| P&T | Peeled and turned |
| ST | Smooth turned |
| CG | Centreless ground |
| CF | Cold finished |
| HF | Hot finished |
| RT | Rough turned/peeled |
| PR | Peeled and reeled |
EN 24 Square Bar
EN 24 Steel Hexagonal Bar
BS970 EN 24 Bright Bar
Steel EN 24 Rounds
EN 24 Alloy Steel Forged Bar
EN 24 Grade Black Bar
DIN 34CrNiMo6 Flat Bar
EN 24 Grade Steel Cold Drawn Bar
Check Chemical Composition table of EN 24 Grade Steel Cold Drawn Bar
Carbon
0.36 – 0.44
Manganese
0.45 – 0.70
Chromium
1.00 – 1.40
Molybdenum
0.20 – 0.35
Silicon
0.10 – 0.35
Sulfur
Max 0.040
Phosphorus
Max 0.035
Nickel
1.30 – 1.70
View Mechanical & Physical Strenght chart of EN 24 Medium Alloy Steel Annealed Round Bar
Tensile Strength
850-1000
Yield Stress
680 Min
Elongation
13 %
Hardness
248/302 HB
Density
7.85 g/cm³
Modulus of Elasticity
210 GPa (30.5 x 10^6 psi)
Thermal Conductivity
45 W/m·K
Thermal Expansion
11.7 x 10^-6 /°C
Melting Point
1425-1540°C (2600-2800°F)
| Export to | Price changes and the expected delivery |
|---|---|
| Egypt | 5 % extra | 18 days |
| Turkey | 5 % extra | 21 days |
| Libya | 5 % extra | 45 to 60 days |
| Nigeria | 5 % extra | 30 days |
| Germany | 5 % extra | 20 days |
