Table of Content
- EN 36 Round Bar Specification
- EN 36 Flat Bar Equivalent Material
- Most Common Types of EN 36 Round Bar
- EN 36 Steel Hex Bar Size
- Conditions of EN 36 Grade Rod
- Chemical Composition of BS970 EN 36 Hex Bar
- EN 36 Standard Bright Bar Physical Properties
- Mechanical Properties of EN 36 Medium Alloy Steel Rounds
Check Specification of AISI 3310 Rounds Quenching & tempering Process
View EN 36 Round Bar Price in India, also Refer EN 36 Flat Bar American Standard
| Werkstoff | BS 970 1991 | BS 970 1955 EN | AISI/SAE |
|---|---|---|---|
| 1.5752 | 655M13 | EN36 | 3415 |
EN 36 Steel Rod
BS970 EN 36 Flat Bar
EN 36 Grade Steel Hex Bar
Steel EN 36 Bright Bar
EN 36 Alloy Steel Black Bar
EN 36 BS970 Forged Bar
EN 36 Grade Rounds
EN 36 Standard Square Bar
View EN 36 Steel Hot Rolled Bar Sizes for more information
| Size Chart | Weight Chart |
|---|---|
| mm | Kilogarm/meter |
| 17 x 17 | 1.985 |
| 21 x 21 | 3.029 |
| 22 x 22 | 3.324 |
| 24 x 24 | 3.956 |
| 18 x 18 | 2.225 |
| 19 x 19 | 2.479 |
| 20 x 20 | 2.747 |
| 25 x 25 | 4.292 |
| 9 x 9 | 0.556 |
| 10 x 10 | 0.687 |
| 11 x 11 | 0.831 |
| 12 x 12 | 0.989 |
| 26 x 26 | 4.642 |
| 28 x 28 | 5.384 |
| 30 x 30 | 6.181 |
| 32 x 32 | 7.032 |
| 34 x 34 | 7.939 |
| 70 x 70 | 33.65 |
| 75 x 75 | 38.629 |
| 7 x 7 | 0.337 |
| 8 x 8 | 0.44 |
| 13 x 13 | 1.161 |
| 14 x 14 | 1.346 |
| 15 x 15 | 1.545 |
| 16 x 16 | 1.758 |
| 36 x 36 | 8.9 |
| 38 x 38 | 9.916 |
| 40 x 40 | 10.988 |
| 42 x 42 | 12.114 |
| 45 x 45 | 13.906 |
| 48 x 48 | 15.822 |
| 50 x 50 | 17.168 |
| 53 x 53 | 19.29 |
| 55 x 55 | 20.774 |
| 60 x 60 | 24.723 |
| 65 x 65 | 29.015 |
| ANN | Annealed |
|---|---|
| H&T | Hardened and tempered. |
| PH | Precipitation hardened |
Check EN 36 Grade Steel Black Bar Chemical Composition
Carbon
0.12-0.18
Sulfur
0.05 max
Mangenese
0.30-0.60
Nickel
3.00-3.75
Molybdenum
0.10-0.25
Silicon
0.10-0.35
Chromium
0.60-1.10
Phosphorus
0.05 max
Density
7.85 g/cm³
Modulus of Elasticity
210 GPa (30.5 x 10^6 psi)
Thermal Conductivity
45 W/m·K
Thermal Expansion
11.7 x 10^-6 /°C
Melting Point
1425-1540°C (2600-2800°F)
Refer EN 36 Alloy Steel Annealed Round Bar Mechanical Properties
CONDITION
ANNEALED
TENSILE STRENGTH
80 (551)
YEILD STRENGTH
35 (241)
ELOGNATION
30
| Export to | Price changes and the expected delivery |
|---|---|
| Norway | 5 % extra | 45 days |
| Germany | 5 % extra | 21 days |
| France | 5 % extra | 28 days |
| Italy | 5 % extra | 28 days |
| Uk | 5 % extra | 30 days |
