Refer BS 970 Hexagon Bar Specification
Stockist of EN 47 Steel Rod, view BS970 EN 47 Hexagon Rod Equivalent Material in India
| Internal Standard | BS | DIN | IS | EN | SAE/AISI | JIS |
|---|---|---|---|---|---|---|
| 50CrV4 | 735A51 | 50CrV4 | 50Cr4V2 | EN47 | 6150 | SUP10 |
EN 47 Grade Flat Bar available as per BS970 standard, View Hardness Range
| Properties | Value |
|---|---|
| Brinell Rockwell Hardness | 150-200 |
EN 47 Steel Hex Bar
BS970 EN 47 Flat Bar
EN 47 Grade Steel Rounds
Steel EN 47 Square Bar
EN 47 Alloy Steel Forged Bar
EN 47 BS970 Bright Bar
EN 47 Grade Black Bar
EN 47 Standard Cold Drawn Bar
Refer Chemical Composition of EN 47 Alloy Steel Hex Bar
Carbon
0.45-0.55
Mangenese
0.50-0.80
Silicon
0.50
Chromium
0.80-1.20
Vanadium
0.06
Vanadium
0.15
Check EN 47 Standard Bright Bar Physical Properties
Density
7.85 g/cm³
Modulus of Elasticity
210 GPa (30.5 x 10^6 psi)
Thermal Conductivity
45 W/m·K
Thermal Expansion
11.7 x 10^-6 /°C
Melting Point
1425-1540°C (2600-2800°F)
Tensile Strength,Mpa
980
Impact,J
71
Elongation, %
14
Yield Strength ,Mpa
835
Reduction of Area,%
50
| Export to | Price changes and the expected delivery |
|---|---|
| Egypt | 5 % extra | 18 days |
| Turkey | 5 % extra | 21 days |
| Libya | 5 % extra | 45 to 60 days |
| Nigeria | 5 % extra | 30 days |
| Germany | 5 % extra | 20 days |
