Table of Content
- C55 Carbon Steel Round Bar Specification
- AISI 1055 Hex Bar Equivalent Material
- Hardness Range of ASTM A510 Rounds
- JIS 1.0535 Flat Bar Quality Certification
- ASME SA510 Square Bar Heat Treatment
- Basic types of C55 Carbon Steel Round Bar
- Chemical Composition of C55 Steel Forged Bar
- C55 Spring Steel Bright Bar Physical Properties
- Mechanical Properties of C55 Carbon Steel Hexagon Rod
DIN 1.0535 Hexagon Bar in wide range of diameters from 3mm – to 76mm, Check Specification
Stockist of ASME SA510 Forged Bar in India, Refer Equivalent
| USA | UK | China | Japan | Australia |
|---|---|---|---|---|
| 1055 | 070M55 / EN9 | 55# | S55C | 1055 |
Exporter of C55 Spring Steel Cold Rolled Round Bar, View Hardness Range
| Properties | Value | |
|---|---|---|
| Hardness | Brinell | 197 |
| Knoop | 219 | |
| Rockwell B | 92 | |
| Rockwell C | 13 | |
| Vickers | 207 | |
| Normalizing | Annealing | Hardening | Tempering |
|---|---|---|---|
| 820-880ºC | 680-710°C | 820-850ºC | 550°C – 660°C |
C55 Carbon Steel Black Bar
DIN 1.0535 Rod
AISI 1055 Hex Bar
JIS 1.0535 Flat Bar
ASTM A510 Rounds
ASME SA510 Square Bar
C55 Steel Forged Bar
C55 Spring Steel Bright Bar
Carbon
0.52 – 0.60
Silicon
≤ 0.40
Mangenese
0.60 – 0.90
Phosphorus
≤ 0.045
Sulfur
≤ 0.045
Nickel
≤ 0.40
Verify the AISI 1055 Rectangular Bar with Chemical Composition
Density
7.85 g/cm³
Melting Point
~1425-1540 °C
Thermal Conductivity
~45 W/m·K
Thermal Expansion
~11.7 µm/m·K
Electrical Resistivity
~0.0005 Ω·m
Check Mechanical Strength of C55 Steel Annealed Round Bar
Elongation (%)
10
Yield Strength
560 MPa
Tensile strength
660 MPa
Modulus of Elasticity
190-210 GPa
Bulk Modulus
140 GPa
Shear Modulus
80 GPa
