Table of Content
- C60 Round Bar Specification
- UNS G10600 Rod Equivalent Material
- AISI 1060 Hex Bar Tolerance
- Most Common Types of 1060 CS Round Bar
- Heat Treatment of AISI 1060 Peeled Round Bar
- C60 CS Square Bar Surface Hardness
- C60 Chemical Composition
- Physical Properties of AISI 1060 Hot rolled Flat Bar
- AISI 1060 Ground Round Bar Mechanical Properties
Check Machined & Forged AISI 1060 Flat Bar in ready stock
1060 Carbon Steel Bar Length
AISI 1060 Round Bar Thickness
1060 Steel Round Bar Diameter
1060 Steel Bar Certification
C-60 Round Bar Density
UNS G10600 Hex Bar Hardness
1060 Cold Drawn Bar Application
1060 HR Steel Bars Finish
AISI 1060 Peeled Round Bars Surface
C60 Carbon Steel Round Bars Tolerance
C60 Carbon Steel Round Bar Uses
Carbon Steel UNS G10600 Bars Cutting Method
Carbon steel UNS G10600 bars Supplier in Mumbai, View Equvalent Material
| China | USA | Australia | UK | Japan |
|---|---|---|---|---|
| 60# | 1060 | 1060 | 070M60 | S60C |
C60 Carbon Steel Rod
UNS G10600 Hex Bar
1060 Carbon Steel Flat Bar
AISI 1060 Hot Rolled Square Bar
AISI 1060 Rounds
Carbon Steel UNS G10600 Forged Bar
1060 carbon steel bar Stock length available in 3000 & 6000, Check Sizes and Tolerance
| Surface Finish | Grinding | Cold Drawn | Turned | Polished | Black-Rolled | Black-Forged | Peeled |
|---|---|---|---|---|---|---|---|
| Tolerance | Best hg | Best H11 | (0, +3mm) | Best h11 | (0, 1mm) | (0, 5mm) | Best H11 |
| Hardening | water or oil quench | 810 – 850°C |
|---|---|---|
| Normalizing | Cooling in air | 820 – 880°C |
| Soft Annealing | Cooling in furnace | 680 – 710°C |
| Tempering | Cooling in air | 550 – 660°C |
| Normal hardenability +H (Hardness HRC – distance mm) | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HRC – mm | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 13 | 15 | 20 | 25 | 30 |
| MIN | 60 | 57 | 50 | 39 | 35 | 33 | 32 | 31 | 30 | 29 | 28 | 27 | 26 | 25 | 23 | 21 |
| MAX | 67 | 66 | 65 | 63 | 62 | 59 | 54 | 47 | 39 | 37 | 36 | 35 | 34 | 33 | 31 | 30 |
Find C60 carbon steel round bars and AISI 1060 ground round bars, With Moly-drop 960
| Grade | C | Cr | Mo | Mn | S | Si | Cr+Mo+Ni | P | Ni |
|---|---|---|---|---|---|---|---|---|---|
| C60/1.0601 | 0.57-0.65 | ≤ 0.4 | ≤ 0.1 | 0.60-0.90 | ≤ 0.045 | ≤ 0.4 | ≤ 0.63 | ≤ 0.045 | ≤ 0.4 |
| C60E/1.1221 | 0.57-0.65 | ≤ 0.4 | ≤ 0.1 | 0.60-0.90 | ≤ 0.035 | ≤ 0.4 | ≤ 0.63 | ≤ 0.03 | ≤ 0.4 |
| C60R/1.1223 | 0.57-0.65 | ≤ 0.4 | ≤ 0.1 | 0.60-0.90 | 0.02-0.04 | ≤ 0.4 | ≤ 0.63 | ≤ 0.03 | ≤ 0.4 |
Density
7.75 g/cm3
Melting point
1470-1510 ℃
Thermal conductivity
22.2 at 100℃ W/m·K
Electrical Resistivity
0.55 at 20℃ μΩ·m
Specific heat capacity
460 at 0-100℃ J/Kg·K
Check Mechanical Properties of UNS G10600 Cold Rolled Round Bar
| Mechanical properties a at room temperature in the quenched and tempered condition (+QT) | |||
|---|---|---|---|
| Elongation, % | ≥11 | ≥13 | ≥14 |
| Diameter d mm | ≤ 16 | 16-40 | 40-100 |
| Tensile Strength Mpa | 850-1000 | 800-950 | 750-900 |
| Thickness t mm | < 8 | 8-20 | 20-60 |
| Yield Strength Mpa | ≥580 | ≥520 | ≥450 |
| Reduction of area ,% | ≥25 | ≥30 | ≥35 |
| Mechanical properties a at room temperature in the normalized condition (+N) | |||
|---|---|---|---|
| Yield Strength Mpa | ≥380 | ≥340 | ≥310 |
| Diameter d mm | ≤ 16 | 16-100 | 100-250 |
| Tensile Strength Mpa | ≥710 | ≥670 | ≥650 |
| Elongation, % | ≥10 | ≥11 | ≥11 |
| Thickness t mm | ≤ 16 | 16-100 | 100-160 |
Delivery Time and Location of 1060 HR Steel Bar
| Export to | Price changes and the expected delivery |
|---|---|
| Canada | 5 % extra | 45 days |
| Mexico | 5 % extra | 45 days |
| Panama | 5 % extra | 45 days |
| Costa Rica | 5 % extra | 45 days |
| Puerto Rica | 5 % extra | 45 days |
