- EN8C Round Bar Specification
- Equivalent Standard of BS970 EN8C Square Bar
- EN8C BS970 Bright Bar Physical Properties
- Most Common types of EN8C Medium Carbon Steel Bar
- Size Chart of EN8C Round Bar
- EN8C Steel Flat Bar Chemical Composition
- Hardness Range of EN8C Carbon Steel Hex Bar
- Mechanical properties of Steel EN8C Forged Bar
Check SAE 1040 Flat Bar Uses & Applications
View Manufacturer of EN8C Steel Flat Bar and Equivalent Standard of BS970 EN8C Square Bar
| Internal Standard | Equivalent Grades | |||||
|---|---|---|---|---|---|---|
| BS | DIN | IS | EN | SAE/AISI | ||
| EN8C | 080A40 | CK45 | 45C8 | EN8C | 1040,1045 | |
Density
7.85 g/cm³
Modulus of Elasticity
210 GPa (30.5 x 10^6 psi)
Thermal Conductivity
45 W/m·K
Thermal Expansion
11.7 x 10^-6 /°C
Melting Point
1425-1540°C (2600-2800°F)
EN8C Steel Hex Bar
BS970 EN8C Black Bar
EN8C Grade Cold Rolled Round Bar
EN8C Grade Steel Square Bar
Steel EN8C Cold Drawn Bar
EN8C Carbon Steel Forged Bar
EN8C BS970 Flat Bar
EN8C Standard Annealed Round Bar
Supplier of EN8C Grade Steel Cold Drawn Bar and Steel EN8C Forged Bar in India
| Diameter | Weight |
|---|---|
| mm | kg/m |
| 14 | 1.21 |
| 16 | 1.58 |
| 18 | 2.00 |
| 10 | 0.62 |
| 12 | 0.89 |
| 20 | 2.47 |
| 30 | 5.89 |
| 32 | 6.84 |
| 35 | 8.29 |
| 40 | 10.18 |
| 22 | 2.99 |
| 25 | 3.85 |
| 28 | 4.83 |
| 45 | 12.65 |
| 50 | 15.40 |
Stockist of EN8C Carbon Steel Hex Bar in Mumbai, Check Chemical Composition
Carbon
0.17-0.24
Silicon
0.17-0.37
Mangenese
0.7-1.00
Sulfur
≤0.035
Phosphorus
≤0.035
Chromium
≤0.25
Nickel
≤0.25
Copper
≤0.25
| Properties | Hardness Range |
|---|---|
| Value | ≤111HB |
Find Mechanical Properties of EN8C BS970 Bright Bar in Cut to length
Tensile Strength (Mpa)
≥380
Yield Strength (Mpa)
≥210
Elongation in 100-150 mm(%)
≥25
Reduction in Area
≥50
Hardness
≤111HB
