Table of Content
- S58C Round Bar Specification
- ASME SA510 Hexagonal Bar Weight Chart
- Equivalent Material of ASME SA510 Rod
- Most Common Types of ASTM A510 Round Bar
- Price List of JIS-S58C Hex Bar
- JIS G4051 Square Bar Chemical Composition
- Physical Properties of JIS G4051 Grade S58C Flat Bar
- ASTM A510 Rounds Mechanical Properties
ASTM A510 Type S58C Flat Bar Internal defects testing with SEP1920 class C, Check Specification
ASME SA510 Round Bar Size
JIS-S58C Rectangular Bar Size
ASTM A510 Hex Bar Size
JIS G4051 Square Bar Size
JIS G4051 Grade S58C Flat Bar Size
JIS-S58C Hex Bar Length
JIS G4051 Square Bar Certifications
JIS G4051 GR S58C Bar Cutting Method
ASTM A510 Rounds Packing
JIS-S58C Bright Bar Application
JIS G4051 Black Bar Shapes
ASME SA510 Rod Tolerance
JIS G4051 Grade S58C Annealed Round Bar Supplier in Mumbai, Refer Weight Chart
| Diameter (mm) | Weight per Meter (kg) |
|---|---|
| 10 | 0.617 |
| 12 | 0.888 |
| 14 | 1.209 |
| 16 | 1.578 |
| 18 | 1.993 |
| 20 | 2.466 |
| 22 | 2.996 |
| 25 | 3.927 |
| 28 | 4.856 |
| 30 | 5.890 |
| 32 | 6.823 |
| 35 | 8.336 |
| 40 | 10.18 |
| 45 | 12.63 |
| 50 | 15.43 |
| USA | Japan | Germany | U. K | France | Italy | Sweden | China |
|---|---|---|---|---|---|---|---|
| AISI/SAE | JIS | WNr. DIN | BS | AFNOR | UNI | SS | GB |
| 1060 | S58C | 1.1221 Ck60 | 080A62 | XC60 | C60 | 1678 | 60Mn |
ASTM A510 Bright Bar
ASME SA510 Rod
JIS-S58C Hex Bar
JIS G4051 Grade S58C Flat Bar
JIS G4051 Square Bar
Have a look on JIS G4051 Forged Bar Price, View Price for more Information
| Size | Price in USD |
|---|---|
| 60MM | USD $ 1.47 |
| 5.8 TO 6.1 MTR | USD $ 0.95 |
| 5.8 TO 6.0 MTR | USD $ 1.17 |
| 20MM | USD $ 1.40 |
| 50MM | USD $ 2.35 |
Get ASTM A510 Rectangular Bar with Manganese Test, Check Chemical Composition
Carbon
0.55-0.61
Silicon
0.15-0.35
Mangenese
0.6-0.9
Phosphorus
≦0.03
Sulfur
≦0.035
Nickel
≦0.2
Density
~7.85 g/cm³
Melting Point
~1420-1460 °C
Thermal Conductivity
~44.5 W/m·K
Electrical Resistivity
~0.0001 ohm·m
Modulus of Elasticity
~210 GPa
Find Typical Properties of ASME SA510 Hot Rolled Bar Stock
Elongation (%)
≥25
Yield Strength
≥210 MPa
Tensile strength
≥380 MPa
| Export to | Price changes and the expected delivery |
|---|---|
| Bangladesh | 5 % extra | 15 days |
| Bhutan | 5 % extra | 7 days |
| Nepal | 5 % extra | 7 days |
| Vietnam | 5 % extra | 10 days |
| Cambodia | 5 % extra | 9 days |
