Table of Content
- SAE 1038 Carbon Steel Round Bar Specification
- Equivalent Material of SAE 1038H Flat Bar
- AISI 1038 CS Hex Bar Hardness Range
- Thermal Properties of SAE 1038 Rod
- 1038 Hot Rolled Square Bar Electrical Resistivity
- Most Commonly Used UNS G10380 Round Bar Types
- SAE 1038 Rounds Chemical Composition
- Physical Properties of AISI 1038 CS Forged Bar
- SAE 1038H Hexagon Rod Mechanical Properties
Manufacturer of UNS G10380 Forged Bar in India, Refer Specification
SAE 1038 Carbon Steel Rod Length
AISI 1038 CS Hex Bar Diameter
UNS G10380 Round Bar Certification
SAE 1038 Rectangle bar Size
UNS G10380 Round Bar Size
SAE 1038H Flat Bar Packaging
1038 Square Bar Cutting Method
SAE 1038 Rounds Tolerance
AISI 1038 CS Forged Bar Technique
UNS G10380 Bright Bar Features
SAE 1038H Hexagon Rod Application
1038 Hot Rolled Black Bar Surface
Supplier of AISI 1038 Carbon Steel Bright Bar in Mumbai, Check Equivalent
| Internal Standard | SAE1038 |
|---|---|
| DIN | CK38 |
| UNS | G10380 |
| SAE/AISI | 1038 |
Supplier of 1038 Hot Rolled Rectangular Bar, View Hardness Range
| Properties | Value | |
|---|---|---|
| Hardness | Brinell | 163 |
| Knoop | 184 | |
| Rockwell B | 84 | |
| Vickers | 170 | |
| Machinability | 65 | |
| Properties | Metric | Imperial |
|---|---|---|
| Thermal conductivity | 51.9 W/mK | 360 BTU in/hr.ft².°F |
| Property | Value |
|---|---|
| Electrical resistivity | 1.43E-7 – 1.74E-7 Ω·m |
SAE 1038 Rod
AISI 1038 CS Hex Bar
UNS G10380 Forged Bar
SAE 1038H Flat Bar
1038 Hot Rolled Square Bar
Stockist & Exporter of SAE 1038H Black Bar, With Chemical Test
Carbon
0.340-0.420
Iron
98.59-99.09
Mangenese
0.60-0.90
Phosphorus
≤ 0.040
Sulfur
≤ 0.050
Density
7.85 g/cm³
Melting Point
~1425-1540 °C
Thermal Conductivity
~45 W/m·K
Thermal Expansion
~11.7 µm/m·K
Electrical Resistivity
~0.0005 Ω·m
Check UNS G10380 Cold Drawn Bar with Corrosion Resistant
Elongation (%)
12
Yield Strength
485 MPa
Tensile strength
570 MPa
Modulus of Elasticity
190-210 GPa
Bulk Modulus
140 GPa
Shear Modulus
80.0 GPa
| Export to | Price changes and the expected delivery |
|---|---|
| Indonesia | 5 % extra | 7 days |
| Thailand | 5 % extra | 7 days |
| Vietnam | 5 % extra | 14 days |
| Bangladesh | 5 % extra | 14 days |
| Mayanmar | 5 % extra | 25 days |
